PT. WIKA BAJA
Kami merupakan Stokis dan Supplier yang menyediakan keperluan industri, kebutuhan baja, dan juga kebutuhan material konstruksi, yaitu seperti :
Besi Beton; WF Beam, H Beam, I-Beam, Besi Siku,
UNP( U-channel) , CNP ( C-channel) , Plate Besi Bordes, etc.;
S45C, ST41, dalam bentuk Roundbar;
SS400 dalam Bentuk Plat dan Profil,
Plate ASTM A36 atau ASME SA36,
As segi enam, As kotak, Plat strip ( Flat Bar) ;
Wire mesh, Wire screen, wire netting ( Stainless, Besi dan Galvanis)
Plate Stainless steel 304, 430, 316, 310 tersedia dalam finish 2B, 1B, BA, finish-4, Hairline;
Aluminium, Kuningan, Tembaga, Bronze ( Plate, Round Bar, Hollow, Pipa) ;
Kawat Las Kuningan, Kawat Las Electrode untuk besi dan Stainless;
Plate lubang / Plate Saringan / Plate Perforated ( Stainless steel, Besi, Aluminum, Galvanis atau ' Spesial Order' ) ;
UNP ( Kanal U) , CNP ( Kanal C) ; Butterfly valve, check valve, Y-Strainer, etc.;
Pipa galvanis, Pipa Carbon Steel API 5L, A53, A106B etc;
Pipa Kotak atau Pipa Hollow atau Pipa Stall;
Plat Bordes atau Plat Kembang atau Plat Chekered ( Stainless, Aluminium atau Besi) ;
Plat Putih ( SPCC) , Plat Hitam ( SPHC) , Atau Plat PO ( SPHC-PO) ;
Roundbar Stainless 304, 316 dan 310; Plate Stainless 201, 304, 430, 316, 310, A253-MA, 3CR12;
Plat Kapal atau Plat Marine dengan Standard BKI, ABS, ataupun LR;
High Tensile Plate ASTM A572 Gr.50, BS EN S355JR, GB Q345 B ataupun
Plate JIS SM490YA / YB;
Pipa Boiler dan Plate Boiler A516 gr.70, SA516 Gr. 70;
Wear Resistance Plate Hardox 400, 500, dan sebanding seperti FORA, BISPLATE, RAEX, XAR ataupun ABREX;
Bronze, Tembanga dan Kuningan ( tersedia dalam bentuk Pipa, Plate dan As) ;
Valve dan fitting ( seperti Butterfly Valve, Check Valve, Y-Strainer, dll ( tersedia dari Material Cast Iron, Stainless, Carbon Steel Class 3000, dll) ;
Kami juga dapat menyediakan keperluan Plate, Pipa atau RoundBar Titanium sesuai dengan permintaan standard ASTM B265, JIS H4600 TP270, ASTM B348, etc.
Kami mohon maaf yang sebesar-besarnya bila email Bapak/ Ibu mengalami keterlambatan untuk tanggapan balasan dari kami.
Besi Beton Polos-Ulir
ukuran dan berat besi beton SNI
besi beton yang kami jual :
besi beton polos.
6mm x 12m = 2, 66 kg
8mm x 12m = 4.74 kg
10mm x 12m = 7.4 kg
12mm x 12m = 10.66 kg
16mm x 12m = 18.96 kg
16mm x 12m = 18.96 kg
19mm x 12m = 26.76 kg
22mm x 12m = 35.76 kg
25mm x 12m = 46.2 kg
29mm x 12m = 62.28 kg
32mm x 12m = 75.72 kg
besi beton ulir
8mm x 12m = 7.74 kg
10mm x12m = 7.4 kg
13mm x 12m = 12.48 kg
16mm x 12m = 18.96 kg
19mm x 12m = 26.76 kg
22mm x 12m = 35.76 kg
25mm x 12m = 46.2 kg
29mm x 12m = 62.28 kg
32mm x 12m = 75.72 kg
DAFTAR BERAT BESI DEFORM DAN POLOS
BERAT BESI BETON POLOS ( PLAIN)
( YANG POPULER DILAPANGAN)
NO JENIS BESI DIAMETER ( Ø ) - PANJANG BERAT ( kg) BERAT per M' ( kg)
1 BESI BETON POLOS 6 MM - 12M 2, 66 0, 22
2 8 MM - 12M 4, 47 0, 37
3 9 MM - 12M 6, 00 0, 5
4 10 MM - 12M 7, 40 0, 62
5 12 MM - 12M 10, 66 0, 89
6 13 MM - 12M 12, 48 1, 04
7 16 MM - 12M 18, 96 1, 58
8 19 MM - 12M 26, 76 2, 23
9 22 MM - 12M 35, 76 2, 98
10 25 MM - 12M 46, 20 3, 85
11 28 MM - 12M 57, 96 4, 83
12 32 MM - 12M 75, 72 6, 31
13 36 MM - 12M 95, 88 7, 99
BERAT BESI BETON ULIR ( DEFORM)
( YANG POPULER DILAPANGAN)
NO JENIS BESI DIAMETER ( Ø ) - PANJANG BERAT ( kg) BERAT per M' ( kg)
1 BESI BETON ULIR 10 MM - 12M 7, 40 0, 62
2 13 MM - 12M 12, 48 1, 04
3 16 MM - 12M 18, 96 1, 58
4 19 MM - 12M 26, 76 2, 23
5 22 MM - 12M 35, 76 2, 98
6 25 MM - 12M 46, 20 3, 85
7 29 MM - 12M 62, 28 5, 19
8 32 MM - 12M 75, 72 6, 31
9 36 MM - 12M 95, 88 7, 99
PT. WIKA BAJA
Distributors Besi Baja-Plate
Head Office Jl. D.I. Panjaitan Kav. 9.1 Jakarta 13340
Phone + 62 21 85533069 ( Hunting ) Fax + 62 21 85533069 Email : info.wikabaja@ gmail.com
SPECFIKASI PLAT KAPAL
Equivalents
DIN 17100, ST 44-2, ASTM A36, ASTM A283 Grade D, EN S275/ BS 43A, AISI 1018, JIS 3101 SS-400
Availability
Thickness: 1.2 mm – 100 mm
Size: Width x Length
42 x 82 ( 1219 x 2438mm) ,
52 x 202 ( 1524 x 6096mm) ,
62 x 202 ( 1828 x 6096mm)
Tabel Ukuran dan Berat Plat ASTM A-36
Product Tebal ( mm) PxL ( feet) Berat ( Kg)
Mild steel 4mm 4 4× 8 = 93.32
Mild steel 4.5mm 4.5 4× 8 = 105
Mild steel 4.8mm 4.8 4× 8 = 112
Mild steel 5mm 5 4× 8 = 117
Mild steel 5.8mm 5.8 4× 8 = 135.32
Mild steel 6mm 6 4× 8 = 140
Mild steel 8mm 8 4× 8 = 187
Mild steel 9mm 9 4× 8 = 210
Mild steel 10mm 10 4× 8 = 233.3
Mild steel 11mm 11 4× 8 = 256.62
Mild steel 12mm 12 4× 8 = 280
Mild steel 13mm 13 4× 8 = 303.3
Mild steel 14mm 14 4× 8 = 326.62
Mild steel 15mm 15 4× 8 = 350
Mild steel 16mm 16 4× 8 = 373
Mild steel 18mm 18 4× 8 = 420
Mild steel 19mm 19 4× 8 = 443.3
Mild steel 20mm 20 4× 8 = 467
Mild steel 21mm 21 4× 8 = 490
Mild steel 22mm 22 4× 8 = 513.3
Mild steel 24mm 24 4× 8 = 560
Mild steel 25mm 25 4× 8 = 583.3
Mild steel 28mm 28 4× 8 = 653.24
Mild steel 30mm 30 4× 8 = 700
Mild steel 31mm 31 4× 8 = 723.3
Mild steel 32mm 32 4× 8 = 747
Mild steel 38mm 38 4× 8 = 887
Mild steel 40mm 40 4× 8 = 933.2
Mild steel 42mm 42 4× 8 = 980
Mild steel 45mm 45 4× 8 = 1050
Mild steel 50mm 50 4× 8 = 1167
Mild steel 65mm 65 4× 8 = 1516.5
Mild steel 75mm 75 4× 8 = 1750
Mild steel 80mm 80 4× 8 = 1870
Mild steel 85mm 85 4× 8 = 1983.1
Mild steel 90mm 90 4× 8 = 2100
Mild steel 100mm 100 4× 8 = 2333
Plat kapal 4.5mm 4.50 5” x 203 328
Plat kapal 6mm 6.00 5” x 203 438
Plat kapal 8mm 8.00 5” x 203 583
Plat kapal 9mm 9.00 5” x 203 656
Plat kapal 10mm 10.00 5” x 203 729
Plat kapal 12mm 12.00 5” x 203 876
Plat kapal 22mm 22.00 5” x 203 1604
Plat kapal 16mm 16.00 5” x 203 1167
Plat kapal 19mm 19.00 5” x 203 1386
Plat kapal 25mm 25.00 5” x 203 1822
Product Thk ( mm) Sheet Size Weight ( Kg)
Marine Plate 4.5mm 4.50 6” x 203 394
Marine Plate 6mm 6.00 6” x 203 525
Marine Plate 8mm 8.00 6” x 203 700
Marine Plate 9mm 9.00 6” x 203 788
Marine Plate 10mm 10.00 6” x 203 875
Marine Plate 12mm 12.00 6” x 203 1050
Marine Plate 22mm 22.00 6” x 203 1400
Marine Plate 16mm 16.00 6” x 203 1664
Marine Plate 19mm 19.00 6” x 203 1926
Marine Plate 25mm 25.00 6” x 203 2188
Daftar Barang/ Harga
Daftar Harga
No. Nama Barang Satuan Harga@ Idr
1 BESI HOLLO 4 X 4 X 1 MM Btg 122, 500
2 BESI HOLLO 4 X 4 X 0, 5 MM Btg 28, 000
3 BESI HOLLO 2 X 4 X 1 MM Btg 99, 000
4 BESI HOLLO 2 X 4 X 0, 5 MM Btg 22, 000
5 BESI BETON 5 MM Btg 26, 000
6 BESI BETON 6 MM Btg 23, 500
7 BESI BETON 8 MM Btg 25, 000
8 BESI BETON 14 MM Btg 79, 000
9 BESI KANAL C 75x2MM Btg 149, 000
10 BESI SIKU 40 X 40 X 2 MM Btg 72, 000
11 BESI SIKU 40X40X3MM Btg 98, 000
12 BESI SIKU 40 X 40 X 6 M Btg 72, 000
13 BESI SIKU 50 X 50 X 3 MM Btg 145, 000
14 BESI SIKU 60 X 60 X 0, 5 MM Btg 363, 000
15 BESI SIKU 40 X 40 TEBAL 3 MM Btg 85, 000
16 BESI HOLLO 40 X 40 X 1 MM Btg 94, 000
17 BESI HOLLO 40 X 20 X 1 MM Btg 79, 000
18 BESI HOLLO 40 X 20 X 0, 5 MM MENI Btg 35, 000
19 BESI HOLO UK. 40 X 40 X 0, 5 Btg 45, 000
20 BESI HOLO GALVANIS 40 X 40 X 0, 7 MM Btg 58, 750
21 BESI HOLO GALVANIS 20 X 40 X 0, 7 MM Btg 52, 250
22 BESI KANAL C 10 X 5 X 0, 4 MM Btg 159, 000
23 BESI RAM tbl 8 mm ulir ( 210x540) M2 525, 000
24 BAJA SSTAR Ø 25X1000 Pcs 496, 000
25 BAJA SSTAR Ø 38X1000 Pcs 1, 145, 000
26 BAJA SSTAR Ø 50X1000 Pcs 1, 983, 000
27 BAJA SSTAR Ø 65X1000 Pcs 3, 345, 000
28 BAJA S50C Ø 16X1000 Pcs 39, 000
29 BAJA S50C TEBAL 28X180X220 Pcs 225, 000
30 BAJA S50C 180X220X30 U/ BACK PLATE Pcs 240, 000
31 BAJA S50C Ø 25X1000 Pcs 94, 000
32 BAJA S50C TEBAL 15X45X1000 Pcs 148, 500.00
33 BAJA S50C 25x200x210 Pcs 215, 000
34 BAJA S50C 25x185x315 Pcs 297, 000
35 BAJA 2316 180X100X50 U/ BODY Pcs 752, 000
36 BAJA 2316 180X50X50
U/ NECK & BOTTOM Pcs 388, 000
37 BAJA 2316 180X33X60 Pcs 306, 000
38 BAJA 2316 180X45X60 Pcs 412, 000
39 BAJA 2316 190X70X40 Pcs 446, 500
40 BAJA 2316 200X40X60 Pcs 414, 000
41 BAJA 2316 70x40x415 Pcs 866, 000
42 BAJA 2316 Ø 60X1000 Pcs 2, 125, 200
43 BAJA 2316 Ø 61X1000 Pcs 2, 135, 000
44 BAJA 2316 Ø 95X1000 Pcs 5, 152, 000
45 BAJA 2316 Ø 41X1000 Pcs 966, 000
46 BAJA 2316 40X60X200 Pcs 413, 600
47 BAJA 2316 35X60X200 Pcs 366, 600
48 BAJA 2316 60X40X180 Pcs 373, 650
49 BAJA 2316 60X50X180 Pcs 460, 600
50 BAJA XW42 Ø 35X1000 Pcs 899, 300
51 BAJA 2379 TEBAL 30X64X500 Pcs 824, 500
52 BAJA DC11 TEBAL 15X55X1000 Pcs 852, 276
53 BAJA DC11 TEBAL 13X54X1000 Pcs 697, 000
54 BAJA DC11 TEBAL 13X63X1000 Pcs 809, 178
55 BAJA DC11 TEBAL 13X64X1000 Pcs 821, 000
56 ALUMUNIUM DURAL Ø 22X1000 Pcs 125, 000
57 ALU.DURAL 180X100X60 Pcs 395, 000
58 ALUMUNIUM DURAL 250X137X50 Pcs 550, 000
59 ALUMUNIUM DURAL 200X180X63 Pcs 750, 000
60 BRONZE Ø 26X1000 Pcs 825, 000
61 PLATE ALU TEBAL 2X1220X2440 mm Pcs 980, 000
62 PLATE ALU TEBAL 1.5X1220X2440 mm Pcs 820, 000
63 PLATE ALU TEBAL 1X1220X2440 mm Pcs 680, 000
64 PLATE DUDUKAN CYLINDER MAT.ALU.DURAL Pcs 675, 000
65 PLAT STANLES LEMBARN U.1, 22X2, 44X 0, 3MM Lembar 500, 000
66 PLATE SIM KUNINGAN t= 0.2X365X1200 Pcs 120, 000
67 PLATE SIM KUNINGAN t= 0.1X365X1200 Pcs 145, 000
68 Plat Bordes tebal 2.4 mm Lbr 640, 000
69 PIPA KUNINGAN Ø 10X1000 Pcs 98, 500
70 PIPA KUNINGAN Ø 8x1000 Pcs 95, 000
71 PIPA KUNINGAN Ø 12X1000 Pcs 140, 000
72 KUNINGAN Ø 5 MM Mtr 10, 000
73 PIPA 1/ 2" GALVANIS Pcs 120, 000
74 PIPA GALVANIS 1" Pcs 225, 000
75 PIPA GALVANIS 4" Btg 1, 535, 000
76 PIPA BESI GALPANIS 1, 5 " X 2 MM Btg 233, 000
77 paralon Ø 2" Mtr 50, 000
78 paralon Ø 2.5" Mtr 72, 000
79 PIPA PVC 1, 5 " Btg 43, 500
80 PIPA PVC 1" Btg 25, 500
81 PIPA PVC 1/ 2" Btg 13, 500
82 PIPA BESI MEDIUM 1, 1/ 4" TEBAL 3 MM Btg 325, 000
83 PIPA TEMBAGA D= 8 MM Roll 265, 000
84 PIPA TEMBAGA DIAMETER LUAR 1/ 4" Roll 185, 000
85 PIPA TEMBAGA DIAMETER LUAR 1/ 2" Roll 370, 000
86 PIPA HOLE 2/ 4 Btg 60, 000
87 TABUNG SILINDER ( BESI) D= 125X145X275 MM Pcs 745, 000
88 KAWAT LOKET 5x5 cm ( tebal kawat 3mm) Mtr 92, 500
89 KAWAT BRC TEBAL 4 MM X 180 CM Mtr 165, 000
90 KAWAT BENDRAT Kg 14, 000
91 KAWAT NYAMUK Mtr 50, 000
92 KAWAT KUNINGAN 0 1, 5 Kg 90, 000
93 Kaca 400 Pcs 290
94 Kaca Polos uk. 146x66.5x0.5 Pcs 80, 000
